WHITE STRIPE TOPLOADERS


White stripe Ford Toploader racing transmissions were used in factory race cars. The gear ratios were custom tailored to the car or track where they were used. These transmissions are extremely rare. The HEH code is hand stamped into the case and there was a white stripe painted over the casting numbers on the cast iron units.

CODE 1st 2nd 3rd Rev
HEH HH 2.74 2.00 1.40 2.74
HEH HF 2.54 1.85 1.30 2.54
HEH HL 2.54 1.69 1.24 2.54
HEH HM 2.54 1.55 1.14 2.54
HEH HA 2.32 1.69 1.29 2.32
HEH HB 2.32 1.54 1.29 2.32
HEH HC 2.32 1.54 1.19 2.32
HEH HE 2.22 1.43 1.19 2.22
HEH HD 2.13 1.56 1.19 2.13
HEH HG 2.02 1.54 1.14 1.96
HEH HJ 1.84 1.42 1.14 1.72
HEH HK 1.76 1.36 1.14 1.65

This is a factory aluminum case used in 69-70 in a few factory road race cars to help lose a little weight. A very small number of these cases were made, maybe 10. This case is stamped HEH HG on the passenger side upper rear corner. The casting number on the driver side is XAA 12512 ALCOA 2.
